Description

About the product

Stainless steel cap (or dished end) is a hemispherical fitting made of stainless steel, used to seal, terminate or blank off the ends of industrial pipelines, pressurized/unpressurized tanks and reactors in a leak-tight manner. It is resistant to corrosion, high pressure and temperature.

Dimensions

Size chart

Sizes are in mm and weights in kg/piece. Just enter the size you need in the quote form.

Nominal Pipe Size	Outside Diameter Outside DiaD	L	SCH 10S		SCH 40S		SCH 80S
Nominal Pipe Size	Outside Diameter Outside DiaD	L	t mm	kg/pcs kg/pcs	t mm	kg/pcs kg/pcs	t mm	kg/pcs kg/pcs
1/2”	21,3	25,4	2,11	0,040	2,77	0,046	3,73	0,045
3/4”	26,7	25,4	2,11	0,052	2,87	0,059	3,91	0,086
1”	33,4	38,1	2,77	0,090	3,38	0,109	4,55	0,109
1 1/4”	42,2	38,1	2,77	0,113	3,56	0,145	4,85	0,159
1 1/2”	48,3	38,1	2,77	0,130	3,68	0,171	5,05	0,222
2”	60,3	38,1	2,77	0,168	3,91	0,234	5,54	0,344
2 1/2”	73,0	38,1	3,05	0,242	5,16	0,420	7,01	0,512
3”	88,9	50,8	3,05	0,362	5,49	0,664	7,62	0,888
4”	114,3	60,3	3,05	0,585	6,02	1,170	8,56	1,510
5”	141,3	76,2	3,40	0,978	6,55	1,900	9,53	2,890
6”	168,3	88,9	3,40	1,350	7,11	2,830	10,97	4,240
8”	219,1	101,6	3,76	2,490	8,18	5,110	12,70	7,760
10”	273,0	127,0	4,19	3,840	9,27	8,920	12,70	13,110
12”	323,8	152,4	4,57	6,150	9,53	14,100	12,70	17,940
14”	355,6	165,1	4,78	7,850	9,53	16,350	12,70	21,110
16”	406,4	177,8	4,78	9,560	9,53	18,600	12,70	25,730
18”	457,0	203,2	4,78	12,100	9,53	23,540	12,70	32,570
